| Model Type | Stationary Flat Board Display |
|---|---|
| Number of Names Held | 1400 |
| Height | 94" |
| Width | 76 1/2" |
| Depth | 13 1/2" main body, and 23 1/2" at the roof peak |
This unit has a display window on one side of the housing with a flat board display. The display area is 53-1/2" wide & 35-1/2" tall and is framed with an oak wood frame. You will use stick pins to attach the copy pages to the board. The housing unit is built from mainly 12 ga. steel. It has a peaked overhanging roof. The steel is sandblasted, primed, painted & coated with a tough STO TEXTURED EXTERIOR FINISH SYSTEM with a WORM GROVED texture that is applied on the exterior surfaces. The unit is vented in 2 places on the bottom of the unit to allow the air inside to vent or breathe. The unit has an anodize dark bronze tinted aluminum window frame and dark bronze painted steel legs. There is a 1/4" thick LOW E TEMPERED glass panel 55-1/4"X 37-1/4". The glass panel removes for access to the inside of the Directory by removing 4 rubber gaskets and 4 aluminum stops. Then the glass panel is lifted out and placed in a safe place while updating the information. This unit comes with a 6"X 24" Cast Aluminum Plaque that has BRONZETONE, Raised Lettering and a border on a dark brown LEATHERETTE Background. It is fastened to the Directory above the window. It can either say "DIRECTORY" or display the name of your Cemetery.
